ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe For Oil Industry

ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe For Oil Industry

  • ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe For Oil Industry
  • ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe For Oil Industry
  • ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe For Oil Industry
  • ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe For Oil Industry
ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe For Oil Industry
商品の詳細:
起源の場所: 中国
ブランド名: YUHONG
証明: ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
モデル番号: ASTM A312 TP321
お支払配送条件:
最小注文数量: 500kg
価格: 交渉可能
パッケージの詳細: 複合木ケース/鉄ケース
受渡し時間: 5~8日
支払条件: L/C,T/T
供給の能力: 月 1500 トン
連絡先
詳細製品概要
スタンダード: ASTM A312 グレード: TP321
Type: 縫い目がない 適用する: 石油産業
メカニカルテスト: 横面試験,長面張力試験,平坦化試験 その他の試験: 溶接破裂試験,静水試験,非破壊電気試験,粒の大きさ (ASTM E112)
ハイライト:

Bright Annealed Seamless Pipe

,

Oil Industry Seamless Pipe

,

TP321 Seamless Pipe

ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe for Oil Industry



Yuhong, a leading metal - manufacturing enterprise with over 30 years of experience and exports to 85 countries, excels in delivering high - quality piping solutions. Specializing in stainless steel products, Yuhong is committed to meeting the strict demands of the oil industry.



For oil - related applications, its ASTM A312 TP321 stainless steel bright - annealed seamless pipes stand out as a top choice. These pipes boast excellent high - temperature resistance and corrosion - fighting ability, thanks to their titanium - stabilized structure. They ensure durability and efficiency in oil exploration, refining, and transportation processes.

ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe Chemical Requirements

Grade UNS Designation Carbon Manganese Phosphorus Sulfur Silicon Chromium Nickel Nitrogen
TP321 S32100 0.08 2 0.045 0.03 1 17.0 - 19.0 9.0 - 12.0 0.1

ASTM A312 TP321 Tensile Requirements



Grade UNS Designation Tensile Strength   Yield, min
ksi MPa ksi MPa
TP321 S32100
Welded   75 515 30 205
Seamless
t ≤ 0.375 in.
[9.50 mm]
  75 515 30 205
t > 0.375 in.
[9.50 mm]
  70 485 25 170

Pipe and Filler Metal Specification



Grade UNS Designation Filler Metal (AWS A5.9 Class) UNS Designation(Filler Metal)
TP321 S32100 ER321
S32180, W32140

Annealing Requirements



Grade UNS Designation Heat Treating Temperature Cooling/Testing Requirements
TP321 S32100 1900 °F [1040 °C] water or other rapid cool

ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe for Oil Industry

  • Corrosion Resistance: TP321 contains titanium, which stabilizes the structure and effectively resists intergranular corrosion caused by high temperatures during oil exploration, refining, and transportation. It can withstand the erosion of various oilfield media such as crude oil, natural gas, and produced water.
  • High - Temperature Performance: In high - temperature sections of oil refining processes like distillation columns and heaters, it maintains good mechanical properties, ensuring stable operation under elevated temperatures without significant deformation or performance degradation.
  • Bright Annealing Advantage: The bright - annealed surface has good smoothness, reducing the adhesion of oil impurities, facilitating cleaning, and minimizing the risk of fouling - related corrosion, which helps maintain the internal cleanliness of the pipeline and the efficiency of oil flow.
  • Seamless Structure Reliability: The seamless design avoids potential leakage points at welds, providing a more reliable pipeline system for the transportation of high - pressure and high - value oil products, enhancing safety and reducing the risk of environmental pollution.

ASTM A312 TP321 Stainless Steel Bright Annealed Seamless Pipe For Oil Industry 0
