| 起源の場所: | 中国 |
| ブランド名: | YUHONG |
| 証明: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| モデル番号: | ASTM A213 TP347 |
| 最小注文数量: | 100kg |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | プラスチックキャップ付きのPly-woodenケース /アイアンケース /バンドル |
| 受渡し時間: | 5〜80日 |
| 支払条件: | L/C、T/T |
| 供給の能力: | 1500トン/月 |
| 処理サービス: | 曲げ、溶接、デカイル、パンチ、切断、成形 | 技術: | コールドロールホットロール |
|---|---|---|---|
| 表面状態: | 、磨かれる、N0.1ピクルスにされるのBA、NO.4のHL、2B | 熱処理: | アニールされる解決 |
| 形: | 円形/正方形/長方形/楕円形 | パック: | 木製のケース |
| ハイライト: | ASTM A213 TP347 boiler tube,stainless steel seamless heat exchanger tube,TP347 stainless steel boiler tube |
||
ASTM A213 covers seamless ferritic and austenitic alloy steel pipe for boilers, superheaters, and heat exchangers. It requires high-temperature performance and nondestructive testing.
TP347 offers high strength and creep resistance at high temperatures. Its excellent oxidation resistance makes it suitable for components exposed to continuous high-temperature environments. In addition to its excellent resistance to intergranular corrosion, it also exhibits good corrosion resistance against a wide range of organic and inorganic acids and alkalines.
Thus, TP347 is a proven and reliable choice for applications involving high temperatures, post-weld use, or temperatures susceptible to sensitization. It is commonly found in core high-temperature equipment in the power generation and petrochemical industries.
| UNS No | Grade | C | Si | Mn | P | S | Cr | Mo | Ni | N | Other |
| S34700 | 347 | 0.08 | 0.75 | 2.00 | 0.045 | 0.030 | 17.00/19.00 | – | 9.00/13.00 | – | Cb:10xC1.00 |
| UNS No | Grade | Proof Stress 0.2% (MPa) |
Tensile Strength (MPa) |
Elongation A5(%) |
Hardness Max | |
| HB | HRB | |||||
| S34700 | 347 | 205 | 515 | 40 | 201 | 92 |
| Properties | Metric | Imperial |
| Density | 7.7 – 8.03 g/cm3 | 0.278 – 0.290 lb/in³ |
Applications
Due to its high-temperature strength and resistance to intergranular corrosion, TP347 seamless pipe is primarily used in the following demanding environments:
Power generation industry
Superheater and reheater tubes for power station boilers
High-pressure, high-temperature steam piping
Petrochemical Industry
Tubes and pipelines for catalytic cracking units, steam reformers, and ethylene cracking furnaces.
Heat exchangers handling corrosive media.
