| 起源の場所: | 中国 |
| ブランド名: | YUHONG |
| 証明: | ABS, LR, GL, DNV, NK, TS, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| モデル番号: | ASTM A312 253MA ステンレス鋼のシームレスパイプ |
| 最小注文数量: | 治療部位により異なります |
|---|---|
| パッケージの詳細: | 合板ケース/鉄ケース/プラスチックキャップ付きバンドル |
| 受渡し時間: | 7日間 |
| 支払条件: | LC、T/T |
| 製品名: | ステンレス鋼のシームレスパイプ | 標準: | ASTM A312/ASME SA312 |
|---|---|---|---|
| 材料: | 253MA / UNS S30815 / EN 1.4835 | od: | 3/8インチ～48インチ |
| wt: | SCH 5SへのSCH XXS | 長さ: | 固定長さ ランダム長さ |
| 終わり: | 平面端 / 斜面端 | タイプ: | シームレス /溶接 |
| 表面: | ピクルスとアニール | ||
| ハイライト: | ASTM A312 stainless steel seamless pipe,Alloy 253MA stainless steel pipe,1.4835 stainless steel seamless pipe |
||
ASTM A312 253MA / UNS S30815 / EN 1.4835 Stainless Steel Seamless Pipe for Industry
253MA is a trademarked name for a high-performance austenitic stainless steel. It is designated under UNS S30815 and the European standard EN 1.4835. It is specifically designed for applications requiring excellent oxidation resistance, good creep strength, and structural stability at elevated temperatures (up to 1150°C / 2100°F). When manufactured to ASTM A312, it signifies that the pipe is a seamless or welded austenitic stainless steel pipe intended for high-temperature and general corrosive service.
You should choose ASTM A312 253MA (UNS S30815) when your operating conditions involve a combination of high temperatures, mechanical stress, and oxidizing environments where standard stainless steels like 304 or 316 would fail prematurely. Choose it if:
The metal temperature exceeds 850°C (1560°F) .
The part is load-bearing at high heat (needs creep strength).
The furnace cycles on/off frequently (thermal cycling).
The environment is oxidizing (excess air) or contains sulfur.
You want to replace 310S but save weight/money with a thinner wall.
Equivalent Grades of ASTM A312 253MA Stainless Steel Seamless Pipe Pickling
| Grade |
UNS |
WERKSTOFF NR. |
EN |
|
|
253MA(UNS S30815) |
S30815 | 1.4835 | X9CrNiSiNCe21-11-2 |
|
Chemical Composition of Stainless Steel Seamless Pipe Pickling
| Grade |
C |
Si |
Mn |
P |
S |
Cr | Ni | Mo | N |
| UNS S30815 | 0.05~0.10 | 1.4~2.0 | 0.80 | 0.030 | 0.030 | 20.0-22.0 | 10.0-12.0 | / | 0.14-0.20 |
Mechanical Properties of ASTM A312 253MA Stainless Steel Seamless Pipe Pickling
| Tensile Str (MPa) min | Yield Str 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | |||
|
600 |
310 | 40 | 95 | 217 |
Application
Due to its high-temperature capabilities, 253MA is a standard material in the following industries:
