ASME SA213 TP304 S30400 Stainless Steel Seamless Tube For Boiler

商品の詳細:

起源の場所:	中国
ブランド名:	YUHONG
証明:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
モデル番号:	ASME SA213 TP304

お支払配送条件:

最小注文数量:	500kg
価格:	交渉可能
パッケージの詳細:	複合木製のケース/鉄製のケース/プラスチックキャップのパッケージ
受渡し時間:	15-20日
支払条件:	L/C、T/T
供給の能力:	月 1500 トン

連絡先

すべての製品

ステンレス鋼のシームレスパイプ (285)

ステンレス鋼の継ぎ目が無い管 (273)

二重ステンレス鋼の管 (127)

二重ステンレス鋼の管 (28)

ニードルチューブ (98)

フィンチューブ (608)

熱交換器 (15)

熱交換器の管 (424)

熱交換管のバンドル (37)

熱交換器Tubesheet (115)

熱交換器のバッフル (36)

エアクーラー (7)

圧力容器 (4)

ステンレス鋼の溶接された管 (57)

ステンレス鋼の溶接された管 (112)

ニッケル合金の管 (259)

ニッケル合金の管 (75)

銅合金の管 (219)

合金鋼の管 (177)

チタニウムの管 (9)

明るいアニールされた管 (153)

ボイラー管 (138)

鋼鉄付属品 (791)

鋼鉄フランジ (577)

ほか (386)

カーネーション部品 (5)

詳細製品概要

スタンダード:	ASME SA213	グレード:	TP304, TP304L, TP316, TP309, TP347
タイプ:	縫い目がない	アプリケーション:	ボイラー
状態:	熱く終わった冷たく終わった	テスト:	水圧試験、非破壊電気試験、粒度（ASTM E112）、圧扁試験、拡管試験
ハイライト:	Boiler Stainless Steel Seamless Tube , Boiler Stainless Seamless Tube , SA213 Stainless Steel Seamless Tube

ASME SA213 TP304 S30400 Stainless Steel Seamless Tube for Boiler Applications

Yuhong Special Steel specializes in ASME SA213 TP304 (UNS S30400) stainless steel seamless tubes for boiler applications. With over 30 years in austenitic stainless steel pipe operations, we ensure quality through strict adherence to standards like ASME SA213. Our TP304 tubes offer excellent corrosion resistance and high - temperature strength, vital for boiler systems. Certified by ABS, DNV, ISO 9001 - 2008, etc., they meet global quality benchmarks. Serving over 85 countries, we provide customized solutions, from size to specification, to support safe and efficient boiler operations in power plants and industrial heating.

Chemical Composition

Grade	UNS Designation	Carbon	Manganese	Phosphorus	Sulfur	Silicon	Chromium	Nickel
TP304	S30400	0.08	2	0.045	0.03	1	18.0 - 20.0	8.0 - 11.0

Heat Treatment and Grain Size Requirements

Grade	UNS Number	Heat Treat Type	Austenitizing/Solutionizing/Stabilizing Temperature	Cooling Media
TP304	S30400	solution treatment	1900 [1040]°^F	water or other rapid cool

Equivalent specification

Region/Organization	Specification System	Grade Designation
China	GB	06Cr19Ni9
Japan	JIS	SUS 304
South Korea	KS	STS 304
USA	ASTM	304
ISO	ISO Designation	X5CrNi 18 - 10
Germany	DIN EN/DIN	X5CrNi 18 - 10 (X5CrNi 18 - 9)
France	NF EN/NF	Z6CN 18 - 09
Russia	GOST	08X18H10

Tensile and Hardness Requirements

Grade	UNS	Tensile Strength	Yield Strength	Elongation	Hardness
TP304	S30400	min, ksi[MPa]	min, ksi[MPa]	in 2 in. or 50 mm, min, %	Brinell/Vickers	Rockwell
		75[515]	30[205]	35	192 HBW	90 HRB
					200 HV

ASME SA213 TP304 S30400 Stainless Steel Seamless Tube for Boiler Applications
ASME SA213 TP304 (UNS S30400) stainless steel seamless tubes are essential for boiler applications, valued for their material properties and standard compliance:

Corrosion & High - Temp Resistance:TP304 resists oxidation and pitting in high - pressure, high - temp boiler environments, ensuring long - term reliability and preventing leakage. Its high - temp strength maintains structural integrity during steam generation and heat exchange.
ASME SA213 Compliance:Manufactured to strict ASME SA213 standards, these tubes meet rigorous quality requirements for pressure - bearing boiler components, from material control to testing.
Operational Efficiency:As heat transfer carriers, they enable efficient steam generation and withstand thermal cycling stresses, supporting safe, long - cycle boiler operation in power plants and industrial heating.
