ISO9626 AISI304 1.4301 Stainless Steel Capillary Tube For Medical Needle Application

ISO9626 AISI304 1.4301 Stainless Steel Capillary Tube For Medical Needle Application

Stainless steel capillary tubes are high-precision steel tubes with small diameter, thin wall and tight dimensional tolerance. These medical grade stainless steel capillary tubes are mainly manufactured by SUS304 raw material, because of its good resistant to corrosion, good durability and formability. Medical capillary tubes are generally welded from stainless steel strips, and cold drawn, annealed, cut (typically 2 meter), straightened, checked for leaks, cleaned, dried, vacuum package. This stainless steel capillary tube is the raw material from which the needle cannula/tube of a medical needle is produced. Its quality directly influences the medical needle's sharpness, strength, penetration performance, and resistance to corrosion during the use process. YUHONG GROUP has more than 30-year manufacturing experience of stainless steel capillary tubes and medical needle tubes/cannula in the medical market.Our medical capillary tubes are produced based on ISO9626 international standard with good surface and excellent size tolerance. If you’re interested in our medical stainless steel capillary tubes, just feel free to contact us for details.

Manufacturing Process:

• Raw Material Selection: AISI 304 / 1.4301 stainless steel strips
• Cold Drawing: The tube is repeatedly drawn through precision dies and over mandrels, reducing the diameter and wall thickness to the final dimensions.
• Annealing: The tube is annealed (heated and cooled in a controlled atmosphere) to soften the steel, relieve internal stresses, and restore ductility, allowing for further drawing without cracking.
• Straightening: The coiled tubes are straightened by the machine..
• Cutting: Cut to specified lengths.
• 100% Dimensional Inspection
• Checking for leaks: Using water pressure to check.
• Cleaning and Packaging: Tubes are meticulously cleaned, degreased, and packaged in a clean environment to prevent contamination.

Key Features:

• High Precision & Tight Tolerances
• Excellent Corrosion Resistance.
• High Strength and Hardness
• Excellent Surface Finish
• Good Ductility and Formability
• Biocompatibility

Medical and Nonmedical Applications:

1) Primary Medical Applications:

• Hypodermic Needles: For injections (subcutaneous, intramuscular, intravenous).
• Biopsy Needles: For tissue sampling.
• Infusion Set Needles: For continuous drug delivery.
• Dialysis Needles
• Spinal and Epidural Needles
• Vascular Access Catheters: Used as the introducer needle for catheter placement.
• Surgical Instrument Components: Such as components for endoscopes, guide wires, etc..

2) Nonmedical Applications:

• Chromatography
• Precision Instrumentation
• Aerospace Industry
• Watchmaking
• Semiconductor Manufacturing
• Jewelry Industry
• Double Glazing Vent
